  • New
Deye HV control box, 200-1000 V, BOS-B-PDU-2-A
  • Deye HV control box, 200-1000 V, BOS-B-PDU-2-A
  • Deye HV control box, 200-1000 V, BOS-B-PDU-2-A

Deye HV control box, 200-1000 V, BOS-B-PDU-2-A

€1,612 Tax included

€1,343 Tax excluded

BOS-B-PDU-2-A is the HV distribution and control unit of the Deye BOS-B Pro-A3 system. It operates from 200 to 1000 V DC, with a nominal current of 180 A, has two PCS ports, a display for state of charge and fault codes, Bluetooth, IP20 protection and a weight of 32 kg.

Reference BOS-B-PDU-2-A

Your legal guarantee rights

Legal guarantee

EU harmonised notice on the legal guarantee of conformity

More information: europa.eu/youreurope/guarantees
Open the notice at full size

BOS-B-PDU-2-A - HV distribution and control unit for BOS-B Pro-A3

BOS-B-PDU-2-A is the power distribution unit (PDU) and high voltage control box of the Deye BOS-B Pro-A3 system. It operates from 200 to 1000 V DC, with a nominal charge and discharge current of 180 A, has two PCS ports and shows the state of charge and fault codes.

Main features:

  • Operating voltage: 200 ... 1000 V DC
  • Nominal current: 180 A, charge and discharge
  • PCS ports: two, PCS1 and PCS2
  • Auxiliary supply: 220 V AC ± 10 %, 2 A
  • Operating temperature: -20 ... 60 °C
  • Ingress protection: IP20
  • Weight: 32 kg

The unit mounts on the top battery pack of the first column. It has a display for the state of charge (SOC) and fault codes, high voltage and alarm indicators, a manual breaker, a USB port for BMS upgrade and storage expansion, Bluetooth for the mobile app and an RS485 interface for emergency power-off.

It needs an auxiliary AC supply to operate. The IN COM and OUT COM ports allow several PDU units to be connected in parallel, and the PCS COM port sends the battery information to the inverter.

Technical specifications

TypePower distribution unit and HV control box
Operating voltage200 ... 1000 V c.c.
Nominal charge/discharge current180 A
Operating temperature-20 ... 60 °C
Ingress protectionIP20
AC input rating220 V c.a. ± 10 %, 2 A
Dimensions (W x D x H)526 x 788.6 x 167.2 mm
Approximate weight32 kg

Data sheet

Reference
BOS-B-PDU-2-A
MPN
BOS-B-PDU-2-A
Product type
BMS and BMS accessories
Battery voltage
HV (high voltage)
Rated current (exact)
180 A
Rated voltage
200 ... 1000 V DC
Communication interfaces
Bluetooth
RS485
Dimensions (H x W x D)
167.2 x 526 x 788.6 mm
Weight
32 kg
Ingress protection (IP)
IP20

We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
