Deye battery, 5.12 kWh, 51.2 V LiFePO4, rack mount, SE-G5.1 Pro-B

Deye battery, 5.12 kWh, 51.2 V LiFePO4, rack mount, SE-G5.1 Pro-B

51.2 V
€1,017 Tax included

€848 Tax excluded

Deye SE-G5.1 Pro-B is a 51.2 V, 100 Ah, 5.12 kWh LiFePO4 battery for 19-inch rack mounting, with a maximum continuous current of 100 A, a built-in 125 A circuit breaker and CAN2.0 and RS485 communication. Up to 64 modules can be connected in parallel, for a capacity of up to 327 kWh.

Reference SE-G5.1 Pro-B

Your legal guarantee rights

Legal guarantee

EU harmonised notice on the legal guarantee of conformity

More information: europa.eu/youreurope/guarantees
Open the notice at full size

Deye SE-G5.1 Pro-B - 5.12 kWh LiFePO4 rack battery

Deye SE-G5.1 Pro-B is a 51.2 V, 100 Ah (5.12 kWh) LiFePO4 battery module designed for standard 19-inch rack mounting. It belongs to the Deye SE series, has an intelligent BMS and a built-in circuit breaker, and communicates with the inverter over CAN2.0 or RS485.

Main features:

  • Nominal voltage: 51.2 V
  • Capacity: 100 Ah, 5.12 kWh
  • Max. continuous current: 100 A, peak 150 A (2 min)
  • Cycle life: 6000 cycles at 90 % DoD
  • Parallel connection: up to 64 modules (327 kWh)
  • Communication: CAN2.0, RS485
  • Ingress protection: IP20

The module uses cobalt-free lithium iron phosphate cells and an intelligent BMS that provides complete protection. Cooling is natural. The operating voltage range is 43.2-57.6 V and the recommended depth of discharge is 90 %. The operating temperature is 0 ... 55 °C for charging and -20 ... 55 °C for discharging.

It can be mounted in a standard 19-inch rack (cabinet depth 600 mm), on a wall or on the floor. Modules connect in parallel, up to 32 without external setup and up to 64 in total (327 kWh). Typical configurations use Deye 12 kW and 15 kW inverters, with 3-12 batteries in parallel.

Technical specifications

Product typeBattery
Battery chemistryLiFePO4 (lithium iron phosphate)
Battery voltage class48 V
Nominal voltage51.2 V
Operating voltage range43.2-57.6 V
Rated capacity100 Ah
Nominal energy5.12 kWh
Usable energy5.12 kWh
Capacity class2.5-6 kWh
Recommended charge / discharge current50 A
Max. continuous discharge current100 A
Max. continuous charge current100 A
Peak current150 A (2 min, 25 °C)
Recommended depth of discharge90 %
Cycle life6000 cycles (25 ± 2 °C, 0.5C/0.5C, 90 % DoD, down to 70 % of capacity)
Parallel connectionup to 64 modules (327 kWh); up to 32 without external setup
Communication interfacesCAN2.0, RS485
Display / indicatormaster LED indicator: 5 LEDs state of charge (20 % ... 100 %), 3 LEDs working, alarming, protecting
Built-in circuit breaker125 A, 2P, 60 Vdc
Ingress protection (IP)IP20
Operating temperaturecharge 0 ... 55 °C, discharge -20 ... 55 °C
Storage temperature0 ... 35 °C
Max. relative humidity5 ... 95 %
Max. operating altitude2000 m
Installationwall, floor or standard 19-inch rack (cabinet depth 600 mm)
Lifetime energy throughput16 MWh (down to 70 % of capacity)
Standards and complianceUN38.3, IEC62619, CE, UK, VDE 2510-50, CEI 0-21, FCC, UL1973, UL9540A
Dimensions (height x width x depth)133 x 440 x 540 mm
Weight45 kg

Data sheet

Reference
SE-G5.1 Pro-B
MPN
SE-G5.1 Pro-B
Product type
Battery
Battery chemistry
LiFePO4 (lithium iron phosphate)
Battery voltage
48 V
Nominal voltage (exact)
51,2 V
Nominal capacity
100 Ah
Capacity class
2.5-6 kWh
Nominal energy
5,12 kWh
Max. continuous discharge current
100 A
Built-in BMS
Yes
Max. charge current
100 A
Communication interfaces
CAN-bus
RS485
Dimensions (H x W x D)
133 x 440 x 540 mm
Weight
45 kg
Ingress protection (IP)
IP20
Operating temperature
0 ... 55 °C (charge), -20 ... 55 °C (discharge)
Max. relative humidity
95 %
Standards and compliance
UN38.3, IEC62619, CE, UK, VDE 2510-50, CEI 0-21, FCC, UL1973, UL9540A

We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
