8 kW Pylontech Force-H3X hybrid inverter, three-phase, HV, FH3X-8K-HY-3P

Name: 8 kW Pylontech Force-H3X hybrid inverter, three-phase, HV, FH3X-8K-HY-3P
Brand: Pylontech
SKU: FH3X-8K-HY-3P
Price: 2325.00 EUR
Availability: InStock

€2,325 Tax included

€1,938 Tax excluded

FH3X-8K-HY-3P is a 8 kW three-phase hybrid inverter with 3 MPPT (200-850 V) and built-in BMS, mounted on 2-7 FH10050 battery modules (10.24-35.84 kWh). It has a maximum efficiency of 98%, a maximum charge and discharge current of 50 A, a back-up output with switchover in 10 ms or less, and Wi-Fi and Bluetooth communication.

Reference FH3X-8K-HY-3P

Your legal guarantee rights

FH3X-8K-HY-3P - Three-phase hybrid inverter 8 kW for HV battery modules

FH3X-8K-HY-3P is the all-in-one controller of the Pylontech Force-H3X system: a 8 kW three-phase hybrid inverter with built-in MPPT and BMS, mounted directly on 2-7 FH10050 battery modules (10.24-35.84 kWh) to form a complete solar storage system, with no extra junction box or switch. The FH10050 modules are not included and are added separately.

Main features:

Rated power: 8 kW
PV input: 3 MPPT, 200-850 V, maximum 12.8 kW
Battery: 2-7 FH10050 modules, 10.24-35.84 kWh
Battery current: 50 A charge and discharge
Maximum efficiency: 98%
Back-up output: 8000 VA, switchover in at most 10 ms
Communication: Wi-Fi and Bluetooth

The controller contains the inverter, the MPPT trackers and the battery management system (BMS). It is installed on 2-7 FH10050 battery modules of 102.4 V and 5.12 kWh (system capacity 10.24-35.84 kWh) and does not use the FC1000 controller of the Force-H3 system. With 2 modules charging can reach 10 kW and discharging 8 kW; with 3-7 modules charging can reach 15 kW and discharging 8 kW.

The PV input has 3 MPPT with one string each, an MPPT range of 200-850 V (full load 280-850 V), a start-up voltage of 200 V, a maximum input voltage of 1000 V, a maximum current of 20 A and a short-circuit current of 30 A per MPPT; the maximum PV power is 12.8 kW. The grid is 3/N/PE, 400 V, 50/60 Hz, with a nominal current to the grid of 11.6 A and a maximum current from the grid of 17.4 A, and the three-phase output accepts 100% unbalanced loads. The back-up output delivers 8000 VA, with a peak of 12000 VA for 60 s, and the changeover between grid and back-up takes at most 10 ms.

The controller box contains the base, the anti-tipping and module brackets, the AC, PV and RJ45 connectors, one energy meter and the mounting accessories; the battery modules are packed separately. The controller has natural cooling, a transformerless topology, a noise level below 30 dB at 1 m, a night-time consumption below 15 W, an LED display, an installed emergency power off (EPO) button and Wi-Fi and Bluetooth communication. It operates at -10...55 °C (power is reduced above 45 °C), at 0-100% humidity, and power is reduced above 2000 m altitude. The user manual states parallel operation of up to 6 units.

Technical specifications

Type	Three-phase all-in-one hybrid inverter, controller with built-in BMS
Battery module model	FH10050
Number of battery modules	2 / 3 / 4 / 5 / 6 / 7
System nominal capacity	10.24 / 15.36 / 20.48 / 25.6 / 30.72 / 35.84 kWh
System nominal power	8 kW
Maximum PV power	12.8 kW
Maximum PV input voltage	1000 V
Start-up voltage	200 V
MPPT voltage range	200-850 V
MPPT full-load voltage range	280-850 V
Number of MPPT	3
Number of PV strings per MPPT	1
Maximum input current per MPPT	20 A
Short-circuit current per MPPT	30 A
PV surge protection	Type II
Maximum continuous charge/discharge current	50 A
Maximum charging power with 2 modules	10 kW
Maximum discharging power with 2 modules	8 kW
Maximum charging power with 3-7 modules	15 kW
Maximum discharging power with 3-7 modules	8 kW
Nominal grid voltage	3/N/PE, 400 V
Nominal grid frequency	50/60 Hz
Nominal continuous current to the grid	11.6 A
Nominal active power to the grid	8000 W
Maximum apparent power to the grid	8000 VA
Maximum continuous current from the grid	17.4 A
Nominal active power from the grid	12000 W
Maximum apparent power from the grid	12000 VA
Power factor range	-0.8...+0.8
Current harmonic distortion (THDi)	< 3 %
Nominal voltage (back-up)	3/N/PE, 400 V
Nominal output frequency (back-up)	50/60 Hz
Maximum continuous current (back-up)	11.6 A
Maximum apparent power (back-up)	8000 VA
Peak off-grid power (60 s)	12000 VA
Grid / back-up switching time	≤ 10 ms
Voltage harmonic distortion (THDv)	< 3 %
Maximum efficiency	98 %
European efficiency	97.5 %
Protections	Anti-islanding, AFCI 2.0 (IEC 63027), insulation resistance monitoring, residual current monitoring, output overcurrent, short-circuit and overvoltage protection, DC switch, DC reverse-polarity protection, PV overvoltage protection, DC/AC surge protection type II
Complete system dimensions, W x H x D (2-7 modules, without base)	540 x 835 / 1005 / 1175 / 1345 / 1515 / 1685 x 350 mm
Complete system weight (2-7 modules, without base)	121 / 160 / 199 / 238 / 277 / 316 kg
Topology	Transformerless
Operating temperature	-10...55 °C (power is reduced above 45 °C)
Operating relative humidity	0-100 %
Altitude	Power is reduced above 2000 m
Noise level (1 m)	< 30 dB
Protective class	I
Overvoltage category	DC II / AC III
Ingress protection	IP65
Salt spray resistance	C5-M
Cooling	Natural
Standby consumption (night)	< 15 W
Communication	Wi-Fi, Bluetooth
Display	LED
Emergency power off (EPO)	Installed
Parallel operation	Up to 6 units
Standards and compliance	VDE-AR-N 4105, EN 50549-1, EN 50549-10, IEC 62109-1, IEC 62109-2, IEC 62619, IEC 62477-1, UN 38.3, VDE-AR-E 2510-50, CEI 0-21, G98, G99

Data sheet

Reference: FH3X-8K-HY-3P
MPN: FH3X-8K-HY-3P
Product type: Inverter
Inverter type: Hybrid (built-in MPPT)
Phases: Three-phase
Power class: 6-10 kW
Continuous output power (W, 25 °C): 8000 W
Peak power: 12000 VA, 60 s
Maximum efficiency: 98 %
Zero-load power: under 15 W
Battery voltage: HV (high voltage)
Max. charge current: 50 A
Max. PV input voltage: 1000 V
Max. PV short-circuit current: 30 A
Number of MPPT trackers: 3
MPPT voltage range: 200-850 V
AC output voltage: 400 V
Output frequency: 50/60 Hz
Max. AC input current: 17.4 A
Parallel operation: Yes
Communication interfaces: Bluetooth
Wi-Fi
Protections: Anti-islanding, AFCI 2.0 (IEC 63027), insulation resistance monitoring, residual current monitoring, output overcurrent, short-circuit and overvoltage protection, DC switch, DC reverse-polarity protection, PV overvoltage protection
Dimensions (H x W x D): 495 x 540 x 350 mm
Weight: 43 kg
Ingress protection (IP): IP65
Operating temperature: -10 ... 55 °C
Max. relative humidity: 100 %
Standards and compliance: VDE-AR-N 4105, EN 50549-1, EN 50549-10, IEC 62109-1, IEC 62109-2, IEC 62619, IEC 62477-1, UN 38.3, VDE-AR-E 2510-50, CEI 0-21, G98, G99

We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
