Deye rack for BOS-A, 13 modules, BOS-A-Rack14
€468
Tax included
€390 Tax excluded
BOS-A-Rack14 is a 14 position rack for the Deye BOS-A series that holds 13 battery modules and one HV control box. It measures 610 x 610 x 2350 mm and weighs 55 kg without modules. It is the rack variant for systems with 11 to 13 battery modules in series.
BOS-A-Rack14 - Rack for BOS-A systems, 13 modules
BOS-A-Rack14 is a 14 position 3U rack for the Deye BOS-A battery series. It holds 13 BOS-A-Pack7.68 battery modules and one high voltage control box, which corresponds to a 99.84 kWh system such as the BOS-A95.
Main features:
- Type: 14 position 3U rack
- Capacity: 13 battery modules and one control box
- Compatibility: Deye BOS-A series
- Dimensions: 610 x 610 x 2350 mm
- Weight: 55 kg, empty rack
The rack is empty: the BOS-A-Pack7.68 modules and the BOS-A-PDU-2 control box are separate products. Systems with 7 to 10 modules use the 11 position rack (BOS-A-Rack11), systems with 14 to 17 modules use two 9 position racks (BOS-A-Rack9 x 2), and systems with 18 to 21 modules use two 11 position racks (BOS-A-Rack11 x 2).
The dimensions and weight are those of the empty rack, as stated in the BOS-A series datasheet.
Technical specifications
| Type | Rack with 14 positions of 3U |
|---|---|
| Capacity | 13 battery modules and one HV control box |
| Dimensions (W x D x H) | 610 x 610 x 2350 mm |
| Approximate weight | 55 kg |
Data sheet
- Reference
- BOS-A-Rack14
- MPN
- BOS-A-Rack14
- Product type
- Accessory
- Dimensions (H x W x D)
- 2350 x 610 x 610 mm
- Weight
- 55 kg
We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
