Orion 48/12-60A DC-DC converter IP20 Victron Energy

Orion 48/12-60A IP20 - DC-DC converter 48 V to 12 V

Orion 48/12-60A IP20 is a non-isolated DC-DC converter that powers 12 V loads from a 48 V battery system, with an output current of 60 A. The remote on/off connector removes the need for a high-current switch in the input wiring and can be operated with a low-power switch or the engine run/stop switch.

Main features:

• Input voltage: 38-66 V
• Output voltage: 10-15 V, adjustable (factory set 13.2 V)
• Output current: 60 A continuous, 65 A maximum
• Maximum efficiency: 92 %
• Remote on/off: remote on/off connector
• Protection rating: IP20

Remote on/off connector
The remote on/off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by the engine run/stop switch (see manual).

All models with adjustable output can also be used as a battery charger
For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.

All models with adjustable output can be paralleled to increase output current
Up to five units can be connected in parallel.
